TOYOTA
CALDINA 2005.1

Images
TOYOTA CALDINA
TOYOTA CALDINA
TOYOTA CALDINA
TOYOTA CALDINA
TOYOTA CALDINA
TOYOTA CALDINA
TOYOTA CALDINA
Description

Modification

ZT

Chassis ID

CBA-AZT241W

Dates releasing

2005.1

Base price, ¥

2,226,000

Body size

4510 x 1740 x 1445 mm

The size of the passenger compartment (LxWxH), mm

1905 x 1455 x 1165 mm

Wheelbase mm

2700mm

Track front / rear wheels, mm

1505mm / 1500mm

Full weight,kg

1310kg

Body type

Wagon

Number of doors/seats

5 door
Engine

Model

1AZ-FSE(D-4)

Type

inline 4 cylinder DOHC 16-valves

Bore x course of the piston, mm

86.0mmx86.0mm

Engine Size

1998cc

Compression ratio

10.5

Fuel injection system

筒内直接燃料噴射装置(D-4)

Maximum power hp / t.min.

155ps(114kW)/6000rpm

Maximum torque, Nm / rpm

19.6kg m(192N m)/4000rpm

Supercharger

--

Fuel tank capacity, liters

60 l

Fuel

Regular unleaded gasoline

Fuel consumption, l/100 km

-
Safe equipment

Driver's air bag

Front passenger air bag

Side airbags

ABS

TRC

Safety belts with tensioner

Safety belts with efforts' limiters

Safety belts with holding

The mechanism of fixation of children's seats

Safety planks

Brake assist

The design of the body, providing energy absorption and dispersion of strike

EBD

Anti theft device

Additional equipment

Steering and suspension

Steering

Power assist equipped rack&pinion

Front suspension

Strut type Coil spring (stabilizer attaching)

Rear suspension

Double wishbone type Coil spring (stabilizer attaching)

Front brake

disk

Rear brake

disk

Front wheel

215/45ZR17

Rear wheel

215/45ZR17

The minimum diameter of a turn

5.4m
Comfort

Air conditioner

Full Auto

Power window

Central switch

Steering column length

Steering column height

Cruise control

Finishing leather steering wheel

leather seats

Power front seat

Power rear seat

Wood panel

Sunroof

alloy wheels

17 inches standard

Folding seat

split

Glass with a UV filter

Toned glasses

Gearbox

Number of steps / Type

4AT

Drive

4AT

LSD

Exterier equipment

Front fog lights

Rear fog lights

Xenon headlights

Additional front headlights

Front / rear spoiler

/

Rear wiper

Navigation, audio and video

Navigation

Navigational device

DVD

Audio

CD-player

Gear ratio

CVT

1

2

3

4

5

6

7

REVERSE

Final drive

3.643
2.008
1.296
0.892
-
-
-
-
2.977
Original car colours
black mica
Super White II
green
Maroon (Brown)
Olive
Navy blue
Purple
Ashes
Yellow
