VOLKSWAGEN
PASSAT 2009.1

Images
VOLKSWAGEN PASSAT
VOLKSWAGEN PASSAT
VOLKSWAGEN PASSAT
VOLKSWAGEN PASSAT
VOLKSWAGEN PASSAT
VOLKSWAGEN PASSAT
VOLKSWAGEN PASSAT
Description

Modification

2.0 TSI SPORTLINE

Chassis ID

ABA-3CCAW

Dates releasing

2009.1

Base price, ¥

4,180,000

Body size

4785 x 1820 x 1475 mm

The size of the passenger compartment (LxWxH), mm

----x----x----mm

Wheelbase mm

2710mm

Track front / rear wheels, mm

1540mm / 1540mm

Full weight,kg

1440kg

Body type

Sedan

Number of doors/seats

4 door
Engine

Model

CAW

Type

inline 4 cylinder DOHC 16-valves IC-turbo

Bore x course of the piston, mm

82.5mmx92.8mm

Engine Size

1984cc

Compression ratio

10.3

Fuel injection system

電子制御

Maximum power hp / t.min.

200ps(147kW)/5100~6000rpm

Maximum torque, Nm / rpm

28.6kg m(280N m)/1700~5000rpm

Supercharger

ic turbo

Fuel tank capacity, liters

70 l

Fuel

Unleaded premium gasoline

Fuel consumption, l/100 km

-
Safe equipment

Driver's air bag

Front passenger air bag

Side airbags

ABS

TRC

Safety belts with tensioner

Safety belts with efforts' limiters

Safety belts with holding

The mechanism of fixation of children's seats

Safety planks

Brake assist

The design of the body, providing energy absorption and dispersion of strike

EBD

Anti theft device

Additional equipment

Steering and suspension

Steering

Power assist equipped rack&pinion

Front suspension

McPherson Strut (stabilizer attaching)

Rear suspension

4リンク (stabilizer attaching)

Front brake

Ventilated disk

Rear brake

disk

Front wheel

235/45 R17

Rear wheel

235/45 R17

The minimum diameter of a turn

5.3m
Comfort

Air conditioner

Full Auto

Power window

Central switch

Steering column length

Steering column height

Cruise control

Finishing leather steering wheel

leather seats

Power front seat

Power rear seat

Wood panel

Sunroof

alloy wheels

17 inches standard

Folding seat

split

Glass with a UV filter

Toned glasses

Gearbox

Number of steps / Type

6AT

Drive

6AT

LSD

Exterier equipment

Front fog lights

Rear fog lights

Xenon headlights

Additional front headlights

Front / rear spoiler

/

Rear wiper

Navigation, audio and video

Navigation

Navigational device

HDD

Audio

CD-player

Gear ratio

CVT

1

2

3

4

5

6

7

REVERSE

Final drive

4.044
2.370
1.555
1.159
0.851
0.672
-
-
3.192
Original car colours
Other black
Other white
green
Maroon (Brown)
Olive
Other Navy blue
Purple
Ashes
Yellow
